hex file, each time you want to program your microcontroller. This is all there is! Now you don’t need to switch between application and reload. If everything is ok, you should see output in console window at the bottom of TrueSTUDIO: Now to program our microcontroller from TrueSTUDIO using this configuration, we need to click on Run -> External Tools -> select one of the configurations (in cas below it is RFM12B_BluPil_001):Īnd click on configuration we want to run. You can also run this configuration here before closing. there exists also -Run, but this one does not work here, actually it blocks TrueSTUDIO because our clone ST-LINK can’t perform this operation.-Rst -> tells ST-LINK CLI to reset our microcontroller after programming.

-p … -> tells ST-LINK CLI where to find hex file of our program.

c SWD -> tells ST-LINK CLI to use SWD interface for programming.

Arguments are data that CLI needs to know where to find our program and what to do with it. Location and Working Directory are locations of ST-LINK CLI and this always stays the same. Name is anything we want, that let’s us know to which program configuration belongs. Then we enter data in all four marked locations. Here we need to add new configuration for each project in which we want to use CLI (maybe there is some shortcuts, but I don’t know it yet):įirst we select New configuration (marked with red). In TrueSTUDIO in menu select: Run -> External Tools -> External Tools Configuration… With this program we can program our microcontroller directly from TrueSTUDIO.

CLI (Command Line Interface) for ST-LINK Utility.

But recently I found new shorter solution for this. And each time you need to load new program into utility and connect to target and program it. If you are using some ST-LINK clone or you are just using SWDIO and SWDCLK to program STM32 microcontroller, you need to use ST-LINK Utility. In this article I will explain how to program STM32 microcontroller directly from TrueSTUDIO using ST-LINK clone we made in previous article.
